Silicon Carbide Kiln Furniture/Shelves
Silicon Carbide Kiln Shelves is widely used in the ceramic and glass industries. It boasts high-temperature stability, wear resistance, and chemical stability. Primarily, it is used to support ceramic products in kilns, maintaining structural integrity at high temperatures and withstanding thermal cycling without deformation.
| Артикул | Silicon Carbide Kiln Shelves |
|---|---|
| Contents | SiC≥90%-99% |
| Bulk Density, g.cm-³ | 2.65-2.75 |
| Кажущаяся пористость, % | < 15 |
| Modulus of Ruture at 20°C, Mpa | 90-100 |
| Modulus of Rupture at 1200°C, Mpa | 100-110 |
| Hardness at 20°C, Kg/mm² | 1800-2000 |
| Fracture Toughness at 20°C, Mpa*M½ | 1.8-2.0 |
| Thermal Conductivity at 1200°C, W/m.k | 35-36 |
| Thermal Expansion at 20-1200°C, 1x10 */°C | 4.6 |
| Thermal Shock Resistance at 1200°C | Very good |
| Max.working Temperature | 1650°C |
The specific types of silicon carbide kiln furniture we can provide are as follows. If you have any questions or needs, please contact us to obtain the latest information and the best quotation!
- Length: 370-800mm;
- Width: 550-1000mm;
- Thickness: 11-20mm;
- D: 20-200mm;
- L: 1500-3000mm;
- Thickness: 4-10mm;
- H: 25-300mm;
- L: 50-4000mm;
- Thickness: 4-12mm;
- D: 20-200mm;
- L: 1500-3000mm;
- Thickness: 4-10mm;
- Used in ceramic kilns (tunnel/shuttle), non-ferrous metal smelting furnaces, steel heating & heat treatment furnaces, glass kilns etc.
- Shape: Round and square;
- Custom Size: Available;
- Apparent porosity: ≤10-18%;
- Outer diameter: 142-1050mm;
- Inner diameter: 110-930mm;
- Overall height: 180-1320mm;
- D: 40-200mm;
- L: 120-800mm;
- Thickness: 3-12mm;
Применение мебели для печей
Пример клиента Керуйского огнеупора
Помимо материкового Китая, компания Kerui Refractory экспортирует продукцию в более чем 50 стран и регионов на 5 континентах мира, включая Азию, Европу, Америку, Африку и Океанию.
Мы получили признание и высокую оценку клиентов по всему миру, и постоянно получаем повторные заказы и рекомендации от клиентов.
-
